Material Texture Loader 1.1 for 3ds Max Full Version

Material Texture Loader 1.1 for 3ds Max Full Version. Compatible with 3Ds Max 2016 to 2020.

The Material Texture Loader is a 3ds Max script designed to quickly load in textures, create a material and apply that to your scene. It works well for a PBR texture workflow, but it can be used for any type of texture that needs to be loaded as part of a material.

Features

  • Automatically create textures with correct gamma input for its material channel, based on name conventions.
  • Link Bitmap and Triplanar Mapping and Coordinates parameters for fast editing of all texture mappings.
  • Easily apply materials to Selected object, Material editor or Drag and Drop functionality.
  • Choose between Standard, Vray, Corona, Redshift or Arnold texture maps and materials.
  • Quickly setup parameters for bitmaps and materials, like Mapping Channel, IOR and Material ID.

Compatibel with 3ds max 2016 to 2020. VRay, Corona, Redshift, Arnold and Standard materials.

Features

  • Automatically create textures with correct gamma input for its material channel, based on name conventions.
  • Link Bitmap and Triplanar Mapping and Coordinates for created textures.
  • Choose between Standard, Vray, Corona, Redshift or Arnold texture maps and materials.
  • Easily apply materials to Selected object, Material editor or Drag and Drop functionality.
  • Quick setup parameters for bitmaps and materials, like Mapping Channel, IOR and Material ID.

Explanation

When you load in a set of textures, the maxscript will put textures into a material slot based on certain name conventions that are present in the filename. So textures that have ‘color’ or ‘albedo’ in there name will go into the Diffuse slot. Reflection, metallic or specular named textures go into the Reflection slot.

You can manually select or de-select textures from any material slot and once you are happy you can select a bitmap and material type, along with a host of other settings.

Once you press ‘Create’, you can apply the material into your scene or material editor.

Gamma for the texture channels set automatically for you. Diffuse, Reflection and Translucency channels are set to gamma 2.2 or sRGB color space. All other gamma values are set to 1.0 or linear color space.

The material texture loader gives the user the ability to add triplanar mapping to all texurtes as well as link Cropping and UVW Coordinates, so when you need to adjust these settings, changes will be applied to all created textures at once. This is very especially useful when working with atlas textures. But it speeds up pretty much the whole material creation process.

Version updates

02-06-2019: updated 1.10

  • Added support for Redshift and Arnold
  • Added triplanar mapping and linking
  • Added AO and emmisve channels
  • Apply to objects, sample slot and slate view
  • Improved channel named recognition and specular, metallic worflow
  • Added extra parameter settings
  • Detects current renderers

13-04-2019: updated 1.02

  • Added support for 3ds Max 2019 and 2020.
  • Added IOR, Metallic and Translucency texture channels.
  • Automatically sets the right Glossniss/Rougness and Metallic settings.
  • Clear and Default texture channels.
  • Set Real-world scale.

07-04-2019: update v1.01

  • Added support for 3ds Max 2016 and 2017.
  • Add material to your material sample slots.
  • Set Blur filtering.
Version Requirement:

2016, 2017, 2018, 2019, 2020

Not tested.

Material Texture Loader 1.1 for 3ds Max Full Version. Compatible with 3Ds Max 2016 to 2020.

or

Please read FAQ if you need basic help.
